Deploy a Fully Local OpenViking on NVIDIA DGX Spark with cuVS

DGX Spark puts the CPU and GPU on one 128 GB pool of unified memory, which is enough to keep the models, the database, and GPU vector search on a single desktop machine. This guide starts from a clean box. You install Ollama and two local models, install OpenViking and NVIDIA cuVS, switch the vector backend to the GPU, run it as a service, and verify the whole path from import to read-back.

What You Will Build

The embedding model turns text into vectors, and the VLM writes the L0 abstract and L1 overview for every file and directory. cuVS accelerates only the dense vector search step. OpenViking keeps directory scoping, scalar filters, and permissions, and hands cuVS a candidate set to search.

Pick a Deployment Path

OpenViking runs as an HTTP service, and there are several ways to run it. The GPU backend narrows the choice for this guide.

The deployment guide covers Docker, Compose, and Helm in full. Before you deploy, decide where the workspace lives, how you will back it up, and who gets which key. The guide's deployment checklist lists these items.

Follow this guide to install and start an OpenViking Server on this machine,
using local Ollama models:

https://docs.openviking.ai/en/getting-started/04-setup-for-agent

Then add the NVIDIA cuVS GPU backend as described in:

https://blog.openviking.ai/post/deploy-openviking-on-dgx-spark/

Ask me before choosing models or opening the server to other machines.
Never print API keys back to me.

Step 0: Check the Machine

nvidia-smi                 # driver 580+, CUDA 13.x
python3 --version          # 3.11 or newer (cuVS 26.06 wheels need it)
uname -m                   # aarch64

OpenViking itself runs on Python 3.10 or newer, and the cuVS 26.06 packages need 3.11. The CUDA major version decides which cuVS package you install: cuvs-cu13 for CUDA 13, cuvs-cu12 for CUDA 12. On the Spark, nvidia-smi reports the total memory usage as not supported because the memory is unified. Read per-process usage with nvidia-smi --query-compute-apps=pid,used_gpu_memory --format=csv instead.

Step 1: Install Ollama and Pull the Models

curl -fsSL https://ollama.com/install.sh | sh
ollama pull qwen3-embedding:0.6b     # embedding, 1024 dimensions, ~639 MB
ollama pull qwen3.6:27b              # VLM, ~17 GB
curl -fsS http://127.0.0.1:11434/api/tags

These are two of the presets the OpenViking setup wizard offers for local models. The table lists more of them, with the RAM the wizard recommends. On a 128 GB Spark every row fits, but the VLM, the vector index, and your other workloads share that one pool, so choose the smallest VLM that gives good summaries.

If you change the embedding model, set its real output size as the dimension in the configuration step, because the index is created with that size.

Step 2: Install OpenViking and cuVS

Use one virtual environment for both, so the server process can import cuVS and CuPy.

python3 -m venv ~/openviking-env
source ~/openviking-env/bin/activate
pip install openviking

# CUDA 13 (use cuvs-cu12 and cupy-cuda12x for CUDA 12)
pip install cuvs-cu13 'cupy-cuda13x[ctk]' --extra-index-url=https://pypi.nvidia.com

The [ctk] extra installs the CUDA toolkit headers that cuVS needs when the host has a driver but no toolkit. See the cuVS installation requirements for the release you pick.

Check the GPU Path Before Adding Models

The repository ships a smoke test that writes vectors and runs a filtered search through cuVS. It needs neither the embedding model nor the VLM, so a failure here points at the GPU stack and nothing else.

git clone --depth 1 https://github.com/volcengine/OpenViking.git
python OpenViking/examples/cuvs_smoke.py

Step 3: Configure OpenViking

Run the setup wizard and choose the local Ollama option for both models. It checks that Ollama is reachable, offers to pull the models, and writes ~/.openviking/ov.conf.

openviking-server init

The wizard does not configure the GPU backend, so open ov.conf and add the storage.vectordb block. The complete file looks like this:

{
  "server": { "host": "127.0.0.1", "port": 1933 },
  "storage": {
    "workspace": "/home/<you>/.openviking/data",
    "vectordb": {
      "backend": "cuvs",
      "distance_metric": "cosine",
      "cuvs": {
        "algorithm": "brute_force",
        "dtype": "float32",
        "max_concurrent_gpu_searches": 1,
        "micro_batching_enabled": false,
        "fallback_to_native": true,
        "filter_cache_size": 16
      }
    }
  },
  "embedding": {
    "dense": {
      "provider": "ollama",
      "model": "qwen3-embedding:0.6b",
      "api_base": "http://localhost:11434/v1",
      "dimension": 1024,
      "input": "text"
    }
  },
  "vlm": {
    "provider": "litellm",
    "model": "ollama/qwen3.6:27b",
    "api_key": "no-key",
    "api_base": "http://localhost:11434",
    "temperature": 0.0,
    "max_retries": 2,
    "extra_request_body": { "num_ctx": 16384, "think": false }
  }
}

• num_ctx and think: Ollama defaults to a 4096-token context, and the memory-extraction prompt alone is about 5k tokens, so the default silently truncates the conversation. The wizard sets 16384 and turns thinking off, because a thinking model can otherwise emit only reasoning and stall.
• fallback_to_native: dense search runs on the GPU, while sparse and hybrid queries fall back to the native index.
• server.host: 127.0.0.1 is the default. In the default development mode, local requests need no key. The section on remote access below covers opening it up safely.

Choose the Backend Mode

On a Spark the VLM and the vector index draw on the same unified memory. If you want OpenViking to use cuVS only when memory allows, keep the backend on local and enable auto mode instead:

"vectordb": {
  "backend": "local",
  "cuvs": {
    "auto_enable": true,
    "algorithm": "brute_force",
    "auto_memory_reserve_mb": 8192,
    "auto_memory_safety_factor": 2.0,
    "auto_background_rebuild": true
  }
}

Before each build, auto mode reads the free device memory, estimates the index size, multiplies it by the safety factor, and keeps the reserve free. If the index does not fit, that query uses the native CPU index and a later query retries. Small filtered scopes also route to the CPU by design, because a few thousand candidates are faster there. The reserve above is an example; size it against the model you run.

Step 4: Check and Start the Server

openviking-server doctor     # validates embedding, VLM, storage, and the vector backend
openviking-server            # keep this terminal open

# in another terminal
curl http://127.0.0.1:1933/health

A healthy server answers {"status":"ok","healthy":true,...}. Only one server can own a workspace: with an embedded vector backend, OpenViking takes an exclusive file lock on storage.workspace. Web Studio, the built-in management UI, is served from the same address at /studio.

Step 5: Connect the CLI

npm install -g @openviking/cli
ov config      # choose Custom, URL http://127.0.0.1:1933, leave the key empty
ov health

Step 6: Verify the Full Path

A passing health check does not prove that models, indexing, and retrieval work together. Run one document through the whole path. Save this as ov-release-rotation.md:

# OpenViking release rotation

OpenViking ships a new release every Friday.
Release owners rotate in this order: qin-ctx, zhoujh01, ZaynJarvis, t0saki.

ov add-resource ./ov-release-rotation.md \
  --to viking://resources/ov-release-rotation --wait --timeout 120

ov tree viking://resources/ov-release-rotation
ov overview viking://resources/ov-release-rotation
ov find "Who owns the weekly OpenViking release?" \
  --uri viking://resources/ov-release-rotation

Then read the file back by the URI that find returns, and compare it with the source. The comparison is the acceptance test, because a successful HTTP status alone does not show that the stored text is intact:

ov read "<returned-file-uri>" > /tmp/readback.md
diff /tmp/readback.md ov-release-rotation.md && echo READBACK_OK

Confirm the Search Used the GPU

Ask for operation telemetry on a search. In the response, summary.vector.cuvs.routes counts the searches by route, and a cuvs entry means the dense search ran on the GPU. builds is 1 on the first search, when the GPU index is built lazily, and 0 afterward.

curl -s -X POST http://127.0.0.1:1933/api/v1/search/find \
  -H "Content-Type: application/json" \
  -d '{"query": "weekly release owner", "target_uri": "viking://resources", "telemetry": true}'

To watch the process from the GPU side, run the per-process query from Step 0 before and after the first search.

Run It as a Service

For a machine that stays on, let systemd keep the server up and start it on boot. This is the recommended way to run OpenViking on Linux, and it works with the virtual environment from Step 2. Replace every <you> with the user that owns the environment and the configuration. Ollama's installer registers its own systemd unit, so the server can start after it.

[Unit]
Description=OpenViking HTTP Server
After=network.target ollama.service
Wants=ollama.service

[Service]
Type=simple
User=<you>
Group=<you>
WorkingDirectory=/home/<you>
ExecStart=/home/<you>/openviking-env/bin/openviking-server
Environment="OPENVIKING_CONFIG_FILE=/home/<you>/.openviking/ov.conf"
Restart=always
RestartSec=5

[Install]
WantedBy=multi-user.target

sudo systemctl daemon-reload
sudo systemctl enable --now openviking.service
sudo systemctl status openviking.service
sudo journalctl -u openviking.service -f

Stop the foreground server from Step 4 first, because only one server can hold the workspace lock. The unit points at the configuration file through OPENVIKING_CONFIG_FILE, so a file under your home directory is used even though systemd starts the service.

Reach It from Your Laptop

The server listens on loopback, so a laptop cannot reach it directly. There are two ways to fix that, and the first is usually enough.

Option 1: An SSH tunnel

ssh -N -L 1933:127.0.0.1:1933 <you>@<spark-host>

# in another laptop terminal
ov config      # Custom, URL http://127.0.0.1:1933
ov health
# Web Studio: http://127.0.0.1:1933/studio

Traffic stays inside the SSH connection, the server never listens on a public address, and no key is needed in the default development mode.

Option 2: Listen on the network with authentication

Use this when several people or machines share the Spark. A non-loopback listener requires a root key, and the server refuses to start in development mode on such an address. Add the listener and the key to ov.conf, then create an account and a user key with the Admin API:

"server": {
  "host": "0.0.0.0",
  "port": 1933,
  "root_api_key": "<a long random secret>"
}

curl -X POST http://127.0.0.1:1933/api/v1/admin/accounts \
  -H "X-API-Key: <root key>" -H "Content-Type: application/json" \
  -d '{"account_id": "team", "admin_user_id": "alice"}'
# returns a user_key; give that key to the client, never the root key

Clients then put the Spark's address and their user key in ~/.openviking/ovcli.conf. A root key is for administration only. Put TLS in front of the server before you expose it beyond a trusted network; the public access guide and authentication cover the options.

Connect Your Agents

A running server is useful once an agent talks to it. Three routes cover most setups:

• Plugins for Claude Code and Codex: run curl -fsSL https://openviking.ai/install | bash, tick the tools to set up, and choose Custom URL with your server address (the tunnel address works). Afterward you use claude or codex as before. The coding agent guide walks through it.
• MCP clients: point any MCP-compatible client at the built-in /mcp endpoint of the server.
• Context Gateway: for clients that cannot install a plugin, such as chat apps and SDK scripts, change only the base URL and the API key. The gateway guide is in beta and explains what it recalls, saves, and compacts.

The integration overview lists every supported agent with a one-line recommendation.

Plan the Memory

The vectors live in two places: a host-side copy that OpenViking keeps for recovery and fallback, and the cuVS dataset on the device. Both are logical allocations from the same unified memory pool. With the default float32, the device payload is N × dimension × 4 bytes. We measured these CuPy allocations for 1024-dimensional vectors on the Spark:

The server process also carries a CUDA runtime baseline of roughly 170 MiB, and the models loaded by Ollama take their own share of the same pool. Setting "dtype": "float16" halves the device payload; measure Recall@K against float32 before you rely on it. The cuVS guide lists the CAGRA graph overhead and the filter-cache cost.

Behavior to Expect

• The GPU index is not persisted. After a restart, OpenViking rebuilds it from the locally stored vectors, and the first dense search pays that cost.
• Inserts, updates, and deletes mark the GPU index dirty. By default the next search rebuilds it synchronously; with auto mode and background rebuild, queries use the CPU index until the new snapshot is ready.
• A built snapshot stays in memory until the next rebuild or shutdown. There is no idle eviction yet, so budget for the full index.
• The CPU path searches an int8-quantized index and the GPU path searches float32 or float16 vectors, so scores and near-tie ordering can differ slightly between the two.

What Speed-up to Expect

We measured exact brute-force search on a 1.94 million vector, 1024-dimensional collection on the Spark, with top-100 results and 8 concurrent clients:

Read these numbers with their limits in mind. They cover the vector recall step only, not the end-to-end latency of an agent. The CPU path searched an int8 index and the GPU path float16, so this is not an equal-dtype kernel comparison. A directory filter leaves fewer candidates, which is why the gain is smaller there and why auto mode keeps a CPU path. The benchmark harness lets you repeat the measurement on your own data.

Tune for Your Workload

Micro-batching supports exact brute-force only and needs max_concurrent_gpu_searches set to 1. Change one setting at a time and re-run the benchmark harness on your data, because crossover points depend on the hardware and the workload.

Troubleshooting

Upgrade and Roll Back

1. Copy the virtual environment, and install the new OpenViking version into the copy. Run pip check there.
2. Stop the server (sudo systemctl stop openviking.service) and back up the whole workspace directory together with ov.conf.
3. Point ExecStart at the new environment, start the service, and run the Step 6 checks again.

To roll back, stop the new server, restore the backed-up workspace, and start the old environment. Do not point the old version at data the new version has written.

What to Try Next

With the server running and an agent connected, import your own documents and see what the agent recalls. Everything in this guide stays on the machine, so the same setup also works for private repositories and documents.
